JDM 2013-2018 SCION FRS SUBARU BRZ FA20 2.0L 4 CYLINDER ENGINE TOYOTA 86

Description

Buy JDM FA20 BRZ FR-S Toyota 86 Engine Online

Buy JDM 2013–2018 Scion FR-S Subaru BRZ FA20 2.0L 4-Cylinder Engine Toyota 86 Online

The JDM FA20 2.0L 4-cylinder engine from the 2013–2018 Subaru BRZ, Scion FR-S, and Toyota 86 is one of the most innovative naturally aspirated performance engines to come from Subaru and Toyota’s joint engineering program. Featuring a horizontally opposed Boxer layout, direct and port fuel injection, and high-revving capability, the FA20 engine is the heart of the modern lightweight sports car movement. At jdmcarpart.com, we provide authentic, direct-import JDM FA20 engines — compression-tested, low mileage, and shipped worldwide — giving you a reliable foundation for replacements, swaps, or performance upgradesBuy JDM FA20 BRZ FR-S Toyota 86 Engine Online.

The FA20 was designed with balance, efficiency, and performance in mind. Unlike turbocharged Subaru EJ engines, the FA20 is naturally aspirated in stock form, delivering crisp throttle response and linear power all the way to its redline. Its compact, low-mounted design lowers the car’s center of gravity, enhancing handling and cornering. Paired with Toyota’s D-4S dual injection system (direct + port injection), the FA20 combines efficiency with responsiveness, ensuring strong performance on the street, track, or touge. Buy JDM FA20 BRZ FR-S Toyota 86 Engine Online

FA20 Engine Overview

• Engine Code: FA20
• Displacement: 1,998 cc (2.0L)
• Configuration: 4-cylinder, horizontally opposed Boxer, NA
• Fueling: Toyota D-4S dual injection (direct + port)
• Compression Ratio: ~12.5:1
• Bore × Stroke: 86 mm × 86 mm (square design)
• Cylinder Head: DOHC, aluminium alloy
• Valvetrain: 16 valves, Dual AVCS (intake & exhaust cam variable timing)
• Output (factory JDM rating): ~200 PS (~197 HP) @ 7,000 RPM
• Torque: ~205 Nm (~151 lb-ft) @ 6,400 RPM
• Redline: ~7,400 RPM
• Applications: Subaru BRZ (ZC6), Scion FR-S (ZN6), Toyota 86 (ZN6)

Why the FA20 is Popular

1. Modern Boxer Platform – Lightweight, efficient, and designed for balance.
2. High Compression Ratio – Provides immediate throttle response and sharp mid-range torque.
3. Dual AVCS + D-4S Injection – Combines technology from both Subaru and Toyota for power and efficiency.
4. High-Revving Character – Loves to spin past 7,000 RPM, perfect for spirited driving.
5. Direct JDM Import Advantage – Low mileage (40,000–60,000 miles typical), better condition than local salvage engines.
6. Versatile Build Potential – Naturally aspirated tuning, turbocharging, or supercharging options available.
7. Affordable Reliability – More cost-effective than rebuilding a worn FA20. Buy JDM FA20 BRZ FR-S Toyota 86 Engine Online

Performance & Tuning Potential

The FA20 is a tuner-friendly platform, despite being NA from factory. Enthusiasts have explored a variety of upgrade paths:

• Stage 1 (Bolt-Ons): Cold air intake, exhaust manifold, catback exhaust, ECU tune = 215–220 HP.
• Stage 2 (Mild Power Adders): Header upgrade, high-flow catalytic converters, flex-fuel (E85) tune = 230–240 HP. Buy JDM FA20 BRZ FR-S Toyota 86 Engine Online
• Forced Induction (Turbo/Supercharger): Kits available to push 280–400 HP with proper fuel and supporting mods.  Buy JDM FA20 BRZ FR-S Toyota 86 Engine Online
• Track Builds: With forged pistons, rods, and fuel upgrades, FA20 builds have reached 500 HP+. Buy JDM FA20 BRZ FR-S Toyota 86 Engine Online

What makes the FA20 unique is its square bore/stroke design (86 mm × 86 mm), providing a balance of high-revving capability and torque delivery, making it one of the most rewarding engines for driver-focused builds.

Installation & Swap Applications

• Direct Fit: 2013–2018 Subaru BRZ, Scion FR-S, Toyota 86 (ZN6/ZC6).
• Swap Candidates: Other Subaru/Toyota chassis with custom mounts, ECU tuning, and wiring.
• Pre-Installation Recommendations: Timing chain inspection, valve cover gasket replacement, spark plugs, coils, and fresh fluids.
• ECU Compatibility: JDM ECU can be integrated, but most builders use USDM ECUs with tuning for emissions compliance.

Common FA20 Reliability Notes

While the FA20 is reliable, there are known concerns that should be addressed proactively:

• Rod Bearings: Upgrade oiling system for high-RPM or forced induction builds.
• Valve Springs: 2013–2016 models had recalls; JDM imports often use revised springs.
• Carbon Buildup: Due to direct injection — mitigated with port injection (D-4S helps here).
• Oil Cooler: Recommended for track or turbo builds. Buy JDM FA20 BRZ FR-S Toyota 86 Engine Online

At jdmcarpart.com, we ensure all FA20 engines are inspected and compression tested, minimizing risks associated with used engines. Buy JDM FA20 BRZ FR-S Toyota 86 Engine Online

Shipping & Warranty

• Condition: Compression-tested, low-mileage JDM import.
• Packaging: Palletized, shrink-wrapped, and insured for global shipping.
• Warranty: 30-day startup warranty covering internal defects.
• Customs Support: Full documentation provided for international buyers.

Why Buy From jdmcarpart.com?

Because we deliver more than just engines — we deliver trust, reliability, and authentic JDM performance:

• Direct import from Japan (no middlemen)
• Verified low-mileage FA20 engines
• Compression tested and inspected before shipping
• Warranty-backed peace of mind
• Expert swap and installation support
• Global freight solutions with insurance. Buy JDM FA20 BRZ FR-S Toyota 86 Engine Online

Whether you’re restoring your daily BRZ, replacing a tired FR-S motor, or building a high-powered Toyota 86 project, the FA20 JDM engine from jdmcarpart.com gives you an authentic, reliable, and performance-ready foundation. Buy JDM FA20 BRZ FR-S Toyota 86 Engine Online

---

10 Frequently Asked Questions (FAQs)

1. Is this a direct fit for my BRZ/FR-S/86?
Yes, the FA20 is the correct motor for 2013–2018 ZN6/ZC6 chassis.

2. Does it include the transmission?
No, this is engine only. Transmission sold separately.

3. What’s the mileage of these JDM imports?
Typically 40,000–60,000 miles due to Japan’s strict inspection laws.

4. Is the D-4S dual injection system included?
Yes, the FA20 comes with Toyota’s direct + port injection system.

5. How much power can the FA20 handle stock?
Up to ~240 HP NA with bolt-ons; 280–300 HP FI safely; 400 HP+ with forged builds.

6. Do I need ECU tuning after install?
Yes, tuning is recommended for optimal performance and safety.

7. Are there known issues with the FA20?
Valve springs (recall addressed in many), rod bearings at high RPM, and carbon buildup.

8. Can this be swapped into other Subaru or Toyota platforms?
Yes, with custom work (mounts, wiring, ECU calibration).

9. Does it come with a warranty?
Yes, 30-day startup warranty included.

10. Why buy from jdmcarpart.com?
Because we source genuine, tested JDM FA20 engines with warranty and worldwide shipping. Buy JDM FA20 BRZ FR-S Toyota 86 Engine Online
